PRESSURE TRANSDUCER 350BAR, CROSS CHANNELS
| Technical Specifications: |
|---|
| Measuring 350 bar |
| Parts in contact with pressure: mechanical connection, stainless steel; FPM gasket |
| Output signal 4 .. 20 mA; 0 .. 350 bar; |
| Nominal temperature range -25 …+85°C |
| Working temperature range -40 …+85°C |
| Storage temperature range -40 … +85°C |
| IP67 protection |
| Supply voltage 12 …35V |
| Electrical connection Deutsch DT04; 4 poles |
| EN 61000-6-1 / 2 / 3 / 4 certifications |
